Model No: SG-GL1100 SG-GL1200 SG-GL1400，SG-GL1600 SG-GL1700,SG-GL1800

Automatic Vacuum Tube Furnace

GL series tube furnace adopts advanced technology research and production of high-performance andenergy-saving new electric furnace, there are single tube, multi-tube, horizontal, vertical, open, singletemperature zone, double temperature zone, multi-temperature zone and other tube furnace types.Theequipment is mainly used in research institutes, industrial and mining enterprises for experiments and smalbatch production.lt has the characteristics of simple operation, high temperature control precision, good heatpreservation effect, large temperature range, good furnace temperature unifomity, multi-temperature zonesingle control, large atmosphere and vacuum selection range.

Quantity :

add to cart

Contact Now

Production Description:

The automatic vacuum tube furnace is a horizontal structure, the upper part is a heating chamber, the bottom electric cabinet and storage rack. The two ends of the furnace tube are sealed with stainless steel flanges, and the air nozzle, valve and pressure gauge are installed on the stainless steel flanges respectively. With different vacuum systems, different vacuum effects can be achieved. The equipment is beautiful in appearance, reasonable in structure design and easy to use.

Main Uses And Applicant Scope:

It is suitable for the reaction experiment of activated carbon and coking coal industry. It can also be used in metallurgy, machinery, light industry, commodity inspection, universities and scientific research departments, industrial and mining enterprises of products vacuum sintering, atmosphere protection and reduction process.
