Five-Zone Tubular Furnace
Production Description:
Both ends of the furnace tube are sealed with stainless steel flanges, stainless steel flanges are installed with air nozzle, valve and pressure gauge, with different vacuum systems can achieve different vacuum effects, the furnace is horizontal structure, five separate control, according to the sample requirements can be controlled respectively, the temperature field is uniform, the furnace tube is fixed on the two ends of the support frame, easy to use, simple to operate, It has the advantages of uniform temperature field, low surface temperature of furnace shell, fast rising and falling temperature rate and energy saving.
Main Uses And Applicant Scope:
Ideal equipment for high temperature sintering, research and development, low temperature treatment and small batch production of various materials in colleges and universities, scientific research institutes, enterprises and technical research and development centers. More precise atmosphere control can be provided for sample experiments. It can be used as a protective gas, a weakly reducing gas, and in a slightly positive pressure state. It has the characteristics of fast sintering speed, high use efficiency and wide application range.
