Model No: SG-GL1100,SG-GL1200 SG-GL1400,SG-GL1600,SG-GL1700 SG-GL1800

Mobile Tube Furnace

GL series tube furnace adopts advanced technology research and production of high-performance andenergy-saving new electric furnace, there are single tube, multi-tube, horizontal, vertical, open, singletemperature zone, double temperature zone, multi-temperature zone and other tube fumace types.Theequipment is mainly used in research institutes, industrial and mining enterprises for experiments and smalbatch production.lt has the characteristics of simple operation, high temperature control precision, good heatpreservation effect, large temperature range, good fumace temperature uniformity, multi-temperature zonesingle control, large atmosphere and vacuum selection range.

Quantity :

add to cart

Contact Now

Production Description:

The mobile tube furnace adopts alumina multi-body fiber curing furnace, the working temperature range is 100℃ to 1600℃, and the programmed temperature control system can be vacuumed and ventilated. The moving speed of the furnace body can be adjusted to realize the purpose of rapid rising and cooling of the sample, and meet the experimental requirements of sudden cooling of materials.

Main Uses And Applicant Scope:

It is suitable for reaction experiment of activated carbon coking coal and heat treatment of metal materials, and can also be used for vacuum sintering, atmosphere protection and annealing process of products of metallurgy, machinery, light industry, commerce, universities and scientific research departments, industrial and mining enterprises.

Mobile Tube Furnaceprogrammed temperature control systemMobile Tube Furnaceprogrammed temperature control system
