Model No: SG-GL1100,SG-GL1200,SG-GL1400,SG-GL1600 SG-GL1700 SG-GL1800

Rotary Tube Furnace

GL series tube furnace adopts advanced technology research and production of high-performance andenergy-saving new electric furnace, there are single tube, multi-tube, horizontal, vertical, open, singletemperature zone, double temperature zone, multi-temperature zone and other tube furnace types.Theequipment is mainly used in research institutes, industrial and mining enterprises for experiments and smallbatch production.lt has the characteristics of simple operation, high temperature control precision, good heatpreservation effect, large temperature range, good furnace temperature uniformity, multi-temperature zonesingle control, large atmosphere and vacuum selection range.
Quantity :
add to cart
Contact Now

Production Description:

        One side of the furnace tube is equipped with an electric gear rotating system, the rotation speed can be adjusted with a digital frequency converter to adjust the speed, and the other end is equipped with a bearing guide, the furnace tube is stable when rotating, and the furnace body can be tilted ≤30°, which is convenient to take and put experimental materials, the furnace tube can be vacuum-pumped, and the atmosphere can be ventilated.

Main Uses And Applicant Scope:

  It is suitable for the chemical analysis of the ashes and carbonization of trace solid or powder samples in the laboratory of universities or institutes. It is also suitable for universities, scientific research institutes, industrial and mining enterprises to do high-temperature atmosphere sintering, atmosphere reduction, CVD experiment, vacuum annealing and other experiments and production.



Rotary Tube FurnaceRotary Tube Furnaceelectric gear rotating systemRotary Tube Furnaceelectric gear rotating systemRotary Tube Furnaceelectric gear rotating system
