Model No: SG-GL1100,SG-GL1200 SG-GL1400,SG-GL1600 SG-GL1700 SG-GL1800
Square Vertical Tube Furnace
GL series tube furnace adopts advanced technology research and production of high-performance andenergy-saving new electric furnace, there are single tube, multi-tube, horizontal, vertical, open, singletemperature zone, double temperature zone, multi-temperature zone and other tube furnace types.Theequipment is mainly used in research institutes, industrial and mining enterprises for experiments and smallbatch production.lt has the characteristics of simple operation, high temperature control precision, good heatpreservation effect, large temperature range, good furnace temperature uniformity, multi-temperature zonesingle control, large atmosphere and vacuum selection range.
Quantity :
Subscribe to our Newsletter
Production Description:
The square vertical tube furnace adopts high purity alumina poly-crystalline fiber curing furnace, good insulation performance, resistance wire heating, and programmed temperature control system. The reactor adopts U-shaped quartz tube and stainless steel flange seal, which can be vacuumed and ventilated atmosphere. Beautiful appearance, reasonable structure design, easy to use and reliable.
Main Uses And Applicant Scope:
It is an ideal equipment for atmosphere reduction, CVD, catalytic reaction and gas heating experiments in universities, scientific research institutes and industrial and mining enterprises.
Square Vertical Tube Furnacehigh purity aluminaprogrammed temperature control system
