Model No: SG-JSL1100、SG-JSL1200、SG-JSL1400、SG-JSL1600，SG-JSL1700，SG-JSL1800
Vacuum Well Type Heating Treatment Furnace
The JSL series shaft furnace features an openable door and optional heating elements such asresistance wire, silicon carbon rods, or silicon molybdenum rods. The furnace body and chamber typicallyadopt a circular shaft structure. lt is specifically designed for high-temperature heat treatments such asquenching, annealing, and normalizing of metals, nonmetals, and other chemical compounds inlaboratories of universities, research institutes, and industrial and mining enterprises. it can be equippedwith a touchscreen for programmable control of the vacuum system, gas filing system, and temperaturecontrol system, offering easy and precise operation. it is primarily used in ceramics, metallurgy, electronicsglass, chemicals, machinery, building materials, metals, and many other customized processes includingtempering,hardening,stress relief, sintering, and welding.
Quantity :
Subscribe to our Newsletter
Product Description:
The small well type furnace adopts the top open door, the resistance wire as the heating element, the double shell structure and the temperature control system. The furnace adopts alumina poly-crystalline fiber material, which has good thermal insulation performance and energy saving.
Main Uses And Application Scope:
Suitable for ceramics, metallurgy, electronics, glass, chemical industry, machinery, refractory materials, special materials, building materials, metal, non-metal, alloy materials tempering, annealing, quenching, solid solution treatment, aging treatment and other heat treatment, and its phase transition process analysis, production and development of equipment.
Main Functions And Features:
1.The furnace adopts alumina poly-crystalline fiber material, good thermal insulation performance, durable, high tensile strength, no stray ball, high purity, energy saving effect is obvious;
2.The heating element adopts resistance wire;
3.The shell can be selected Q235/304 stainless steel design, the inner tank can be selected 310S stainless steel material;
4.Turn on power off, leakage protection, high temperature alarm, to ensure the normal use of equipment.
5.Our software equipment through 485 or USB interface and computer interconnection, can achieve a single or multiple electric furnace remote control, real-time tracking, history, output reports and other functions; Paperless recording device can be installed to realize data storage and output;
6.Optional through the touch screen operation of the vacuum system, inflation system, temperature control system for program control, simple operation.
Vacuum Well Type Heating Treatment Furnacedouble shell structuretemperature control systemVacuum Well Type Heating Treatment FurnaceVacuum Well Type Heating Treatment Furnacedouble shell structureVacuum Well Type Heating Treatment Furnacedouble shell structuretemperature control systemVacuum Well Type Heating Treatment Furnacedouble shell structuretemperature control systemVacuum Well Type Heating Treatment Furnacedouble shell structuretemperature control system
The small well type furnace adopts the top open door, the resistance wire as the heating element, the double shell structure and the temperature control system. The furnace adopts alumina poly-crystalline fiber material, which has good thermal insulation performance and energy saving.
Main Uses And Application Scope:
Suitable for ceramics, metallurgy, electronics, glass, chemical industry, machinery, refractory materials, special materials, building materials, metal, non-metal, alloy materials tempering, annealing, quenching, solid solution treatment, aging treatment and other heat treatment, and its phase transition process analysis, production and development of equipment.
Main Functions And Features:
1.The furnace adopts alumina poly-crystalline fiber material, good thermal insulation performance, durable, high tensile strength, no stray ball, high purity, energy saving effect is obvious;
2.The heating element adopts resistance wire;
3.The shell can be selected Q235/304 stainless steel design, the inner tank can be selected 310S stainless steel material;
4.Turn on power off, leakage protection, high temperature alarm, to ensure the normal use of equipment.
5.Our software equipment through 485 or USB interface and computer interconnection, can achieve a single or multiple electric furnace remote control, real-time tracking, history, output reports and other functions; Paperless recording device can be installed to realize data storage and output;
6.Optional through the touch screen operation of the vacuum system, inflation system, temperature control system for program control, simple operation.
